Show the assembly context
Provide a drawing or model of the component and relevant mating parts. Explain the joint function, motion or alignment requirements, and interfaces that affect assembly.
Identify datums and critical features
Mark bearing seats, bores, bolt patterns, locating faces, threads, and other functional geometry only when present in the design. Connect dimensions to assembly acceptance.
Specify material and finish
State material grade and condition, surface requirements, coatings, and protected areas from the approved drawing. Do not leave wear or corrosion assumptions implicit.
Define inspection and changes
List acceptance criteria, requested measurement records, and sample approval requirements. Keep design changes under the buyer or engineering approval process.
Confirm the machining scope
Ask the supplier to review geometry, included operations, finish, inspection, and assumptions before order release. See CNC milling capabilities and share assembly details through the quote page.
