Advantages

Show feature relationships

Identify datums, hole patterns, pockets, slots, and mating faces.

Flag access questions

Request review of deep, narrow, angled, or intersecting features.

Define measurable acceptance

Mark critical dimensions and the records needed to verify them.

Confirm finishing scope

State finish requirements and which dimensions are checked before or after treatment.

Define Milled Features on the Drawing

Precision CNC milled parts are easier to quote when the drawing shows the surfaces and features that control fit, location, and function. Identify datums, pockets, slots, hole patterns, bosses, threads, and mating faces. Do not assume a numeric accuracy from a general description; state the tolerances required for the specific part.

Clarify Feature Access and Relationships

For deep pockets, narrow slots, angled faces, or intersecting holes, ask the supplier to review access, setups, and measurement. If several features must align, identify their datum relationship and indicate which dimensions need inspection records.

  • Provide a current drawing and supporting CAD model when useful.
  • Specify material, finish, quantity, part number, and revision.
  • Mark critical hole locations, faces, and interface dimensions.
  • Call out threads, inserts, edge conditions, or secondary operations.
  • Ask for setup assumptions, inspection scope, and exclusions in the quote.

For general milling RFQ preparation, use the China CNC milling service guide. For multi-face or intricate geometry, review complex CNC parts planning.

Agree on Inspection and Finish

State the required surface finish and which dimensions control acceptance. Ask when dimensions are measured if a later finishing operation may affect them. Confirm the report format, quantity basis, packaging, shipping, and any excluded work before approving the quote.

Frequently Asked Questions

What should a milled-part drawing show?

Show datums, pockets, slots, hole patterns, threads, mating faces, material, finish, tolerances, and acceptance requirements.

Why should deep pockets and narrow slots be reviewed?

Feature access and geometry can affect setups, tooling, and inspection. Ask for a part-specific review before quote approval.

Should I specify a tolerance for every milled feature?

Use appropriate requirements for all dimensions, with tighter controls on features that affect fit or function.

When should dimensions be measured after finishing?

State the acceptance basis, especially when coating or other finishing can affect a critical feature.

How do I compare milled-parts quotes?

Compare the same revision, material, finish, quantity, included operations, inspection, shipping, and exclusions.

Frequently Asked Questions

What should a milled-part drawing show?

+

Show datums, pockets, slots, hole patterns, threads, mating faces, material, finish, tolerances, and acceptance requirements.

Why review deep pockets and narrow slots?

+

Access and geometry can affect setups, tooling, and inspection. Request a part-specific review before quote approval.

Should every milled feature have a tight tolerance?

+

Use appropriate requirements for all dimensions and tighter controls only on features that affect fit or function.

When should dimensions be measured after finishing?

+

State the acceptance basis, especially when coating or finishing can affect a critical feature.

How do I compare milled-parts quotes?

+

Compare the same revision, material, finish, quantity, operations, inspection, shipping, and exclusions.
